CB350F Project MV |
|
A unique range of parts for your street or track project Most parts are CNC machined from 6061/6082 T6 aluminium billet. Customise your CB350/400F, some parts will also fit the bigger SOHC four Hondas, |
|
|
Manufactured from 50x25 steel tube, fully tig welded construction. Supplied complete with stainless steel axle, aluminium spacers, roller bearing pivot with seals, alloy chain guard, oe shock mount rubbers. Powder coated black or can be ordered uncoated. Direct replacement for the stock swingarm. This was a popular conversion in the 70's, unavailable for many years until now. Will fit the CB350/400F. This design is now discontinued.......Coming soon, New re-designed one of a kind swingarm. Also fitment for the CB750 K models.
|
|
| Billet triple tree - Part # 400-003 CNC machined from a chunk of 6082 aluminium, designed to fit the stock 33mm forks, comes complete with removeable steering stops and a aircraft grade 7075 T6 aluminium steering stem. Perfect for a road or a track bike , can be used with the stock upper tree or the TTR billet upper tree. * Reduce fork flex = improved handling! * Total weight = 1.168 Kg's * Stainless hardware *Looks the biz, wow very trick!! * New design # 2 shown, click on the photo to see design #1. * available in a choice of anodised colours or polished.
|
|
|
Top Triple tree. Part # 400-002 Machined from a chunk of 6082 billet. * Anodised or polished finish. Photo shows in raw finish. * Fits the stock handle bars. * All mounts for ignition key and clocks. * Trick part to match the billet lower tree. * Note: DISCONTINUED.
|
| Top Triple tree. Part # 400-001 Top triple for the 400F Must use clip-on bars. Available polished or anodised in a choice of colours. Photo shows triple anodised bright black finish. Mounts for ignition switch and stock clocks included.
|
|
 |
Billet triple tree nut - Part # 400-006 Billet alloy top tree nut, direct replacment for the stock item. * Anodised in a choice of colours. * Lighter than stock. * Available with or without center fuel tank breather hole. * Fits other Honda motorcylces, even a modern fireblade!
|
| Billet chain adjusters - Part # 400-026 Billet chain adjusters, sold per pair, for use with the stock swingarm. * Anodised in a choice of colours. * Uses the oe hardware. * Improves the look of any 350/400F. * Might fit other models.
|
 |
 |
Front fork spring pre-load adjusters - Part # 400-064 Allows the adjustment of the front fork sag, by pre-loading the springs. Only found on modern forks. * Only for the CB400F all years. * CNC machined from high spec aluminium. * Replaces the stock fork caps. * Allows aprox 20mm of pre-load. * Anodised in a choice of colours.
|
| Billet spacer kit - Part # 400-025 Billet spacer kit, anodised aluminium. 4 spacers in set. * 2 x rear wheel spacers.( for stock swingarm) * 1 x front wheel spacer. * 1 x rear top motor spacer. * Choice of anodised colours.
|
 |
 |
Brake reservoir cap - Part # 400-033 Anodised or polished Aluminium alloy. Great shape! * Will also fit many of the classic SOHC 4's and even a modern GSXR1000 and Yamaha R1 98-05. * Choice of colours. * Direct replacment. * Uses the oe seals.
|
| Stainless steel front wheel axle - Part # 400-021 Replaces the stock item. * Corrosion free. * Stainless steel.
|
 |
 |
Special race front wheel axle - Part # 400-022 20mm hollow axle with new bearings, greatly improved fork rigidity. * Stainless steel. * Includes aluminium hub spacer. * New 6004 20mm bearings. * Race use only. * Can not use speedo drive. * Also available to order in 6AL4V Gr 5 Titanium. price on application.
|
| Sprocket mounting studs - Part # 400-028 Set of 4 made from stainless steel. * As per oe design. * Corrosion free.
|
|
 |
Aluminium battery box - Part # 400-065 Manufactured from 2.0mm aluminium, to fit a Yamaha R6 battery. Some drilling required to fit and relocation of electrics. * Race use only. * Stock unit can not be used. Air filter can not be used. * Bracket for starter solanoid included. * DISCONTINUED.
|
| Front stand bobbins. Part # UNI-006 Very handy for the racer or street rider. * Anodised in red,silver,black, blue or gold. * Leave them on or install in minutes when you need to remove the front wheel. * Uses the bottom rear or front fender stay location. * Sold in pairs. |
 |
